ACTi B63 2MP 3x Zoom Indoor Dome Camera

ACTi

ACTi B63 2MP 3x Zoom Indoor Dome Camera

$645.00
Discontinued
SKU: B63
Link to Manufacturer's Page

Contact

ACTi B63 Features:

  • Image Sensor: 1/2.8" Progressive Scan CMOS
  • Effective Pixels: 1944 (H) x 1224 (V) (2.38 MP)
  • Day / Night: Yes
  • Low Light Sensitvity: Superior
  • Minimum Illumination: Color: 0.1 lux at F1.3 (30 IRE, 2400°K); B/W: 0 lux (IR LED on)
  • Mechanical IR Cut Filter: Yes
  • IR LED: Adaptive IR LED x 10 (850nm)
  • IR Working Distance: 40 m (0 lux, 30 IRE, Gain 255, Auto shutter mode)
  • Focal Length / Aperture: Zoom, f3 - 9mm / F1.3 - 2.2
  • Zoom Ratio / Speed: 3x optical / 1 sec (wide to tele)
  • Iris: DC iris
  • Focus: Auto focus
  • Lens Mount: Board mount
  • Horizontal Viewing Angle: 113.7°~38°
  • Compression: H.264 (Baseline / Main / High profile), MJPEG
  • Max. Frame Rate vs. Resolution: 60 fps at 1920 x 1080; 60 fps at 1280 x 720; 30 fps at 640 x 480; 30 fps at 320 x 240
  • Image Enhancement: Extreme WDR (145 dB); White balance: automatic, hold and manual; Brightness; Contrast; Sharpness (auto); Auto gain control; 2D + 3D Digital noise reduction; Flickerless; **Defogging; User defined text on video; Privacy Mask 20 configurable regions; Image Rotation
  • Built-in Analytics: Motion Detection, Tamper, Digital Image Stabilizer, **Line Crossing, **Appear in Area, **Missing Object, **Unattended Object (**Will be available in the future)
  • Audio-In: Terminal block
  • Audio-Out: Terminal block
  • Security: IP address filtering; HTTPs encryption; Password protected user levels; Anonymous login; IEEE802.1X network access control
  • Alarm Trigger: Video motion detection (3 regions); External device through digital input; Sound detection
  • Alarm Response: Notify control Center; Change camera settings; Command other devices; E-mail notification with snapshots; Save video or snapshot to local storage; Upload video or snapshot to FTP server; Activate external device through digital output
  • Local Storage: MicroSDHC memory card slot (card not included)
  • Power Source / Consumption: PoE Class 3 IEEE802.3af / 12.95 W; DC 12V (adapter not included) / 11 W
  • Weight: 709 g (1.56 lb)
  • Dimensions (Ø x H): 146 mm x 107 mm (5.7'' x 4.2'' )
  • Environmental Casing: Vandal resistant (IK09), Transparent dome cover
  • Operating Temperature: -20 °C ~ 50 °C (-4 °F ~ 122 °F)
