ACTi RAS-101 2-Bay Wireless Mini Standalone Retail Application Suite with HDMI and Display
ACTi RAS-101 2-Bay Wireless Mini Standalone Retail Application Suite with HDMI and Display po

ACTi

ACTi RAS-101 2-Bay Wireless Mini Standalone Retail Application Suite with HDMI and Display po

$1,475.20
Discontinued
SKU: RAS-101
Link to Manufacturer's Page

Contact
  • Total Traffic Performance vs Weather
  • Total Traffic Performance vs Gender/Age
  • Total Traffic Performance vs Weather vs Gender/Age
  • Gender distribution pie chart
  • Age distribution bar chart
  • Export Report to Excel
  • Customizable layout for media display
  • 1-bay Mini Standalone Market Application Suite
  • Maximum Number of Video Devices: 10 (People Counting); 1 (Heat Map); 3 (Age and Gender Detection); 5 (Digital Signage); 3 (Face Recognition)
  • Free License: 4 (for LMAS4000 license)
  • Location-based management with e-Map
  • Recommended add-on 1TB storage to keep stored face recognition data at least 7 days
  • Intel Celeron J4005, 4GB

Device

Product Type Standalone Market Application Suite
Product Application Retail Application
Maximum Number of Video Devices 10 (People Counting); 1 (Heat Map); 3 (Age and Gender Detection); 5 (Digital Signage); 3 (Face Recognition)

Hardware

CPU Intel Celeron J4005
RAM 4GB, DDR4, 2400MT/s, maximum up to 8GB

License

License required Yes
Free License 4 (for LMAS4000 license)

Market Application Suite Features

Main Features ● Total Traffic Performance vs Weather
● Total Traffic Performance vs Gender/Age
● Total Traffic Performance vs Weather vs Gender/Age
● Gender distribution pie chart
● Age distribution bar chart
● Export Report to Excel
● Customizable layout for media display
Device Health Monitoring ● MAS Server Health Monitoring
System Management ● User Permission Management
● Store Name Customization
● Floor Map Customization
● Camera Configuration
● MAS Server Configuration
● IVS Setting
Traffic Performance Number of people going in and out from specific entrance or exit for defined period of time. The results from multiple entrances can be compared to define the best time and location for future in-store campaigns.
Total Traffic Performance vs Weather Total traffic performance can be mapped with weather information for correlation analysis to predict future trends of traffic based on weather forecast.
Total Traffic Performance vs Gender/Age (Requires Age/Gender detection module be activated. It requires activation license)
Total Traffic Performance vs Weather vs Gender/Age (Requires Age/Gender detection module be activated. It requires activation license)

Map

e-Map Yes

Audio

Audio Type 2-way, Mic-in, Line-out

Network

Ethernet Port 1 x Ethernet (10/100/1000 Base-T), RJ-45 connector

System

Server Operating System Windows 10 Pro
USB 1-Port USB 3.1 Gen1 Type C, 3-Port USB 3.1 Gen1, 1-Port USB 2.0

Storage

System Drive M.2 SSD, 128GB
Storage Bay SATA, Max. 1 Disk(s) (optional for project request)
M.2 (NGFF) SSD, Max. 1 Disk(s) (optional for project request)
Recommended add-on 1TB storage to keep stored face recognition data at least 7 days
HDD Size 2.5"

Interface

Audio Interface Combo Audio Jack
Wireless Wi-Fi (IEEE 802.11 a/b/g/n/ac), Bluetooth V5.0
Local Access USB keyboard & mouse
Local Display Interface HDMI x 1, Mini Display Port x 1

General

Power Source DC 19V (adapter not included), 3.42 A
Weight 700g (1.54lb)
Dimensions (W x H x D): 115mm x 49mm x 115mm (4.53" x 1.93" x 4.53")
Bundled Accessories VESA 10x10 cm, Power cord
Mount Type VESA mount 10x10
Operating Temperature 0°C ~ 50°C (32°F ~ 122°F)
Operating Humidity 20% - 85% RH
Approvals CE, FCC, UL, BSMI, CB, C-Tick, VCCI
Color Black
Warranty 1 Year(s). For extended warranty offering, see http://www.acti.com/support/warranty

2-Bay Wireless Mini Standalone Retail Application Suite with HDMI and Display port, 4-channel free license included, 2-Bay (Storage Disks not included), Wireless (WIFI, Bluetooth), Audio, DC 19V
