Arecont Vision MegaBall® 2 Model Options (-D, -D-LG, -W)
Arecont Vision AV5245DN-01-DA-LG (light gray)
Arecont Vision AV5245DN-01-DA-LG MegaBall® 2 IP Network Camera

Arecont Vision

Arecont Vision AV5245DN-01-DA-LG MegaBall® 2 IP Network Camera

Sale price$1,200.00
SKU: AV5245DN-01-DA-LG


Arecont Vision AV5245PM-DA-LG Features

  • Max Resolution: 2592 x 1944
  • Image Sensor: 1/2.5" CMOS
  • Day/Night: Yes
  • Mechanical IR Cut Filter: Yes
  • Minimum Illumination: Color: 0.3 Lux; Color Binning: 0.15 Lux; B/W: 0 Lux, IR Sensitive
  • IR Illuminators: No
  • IR Illuminator Range: N/A
  • Lens Type: Motorized Varifocal
  • Focal Length: Panamorph lens
  • Zoom: No
  • Iris: N/A
  • Focus: Manual
  • Field of View: 182° horizontal
  • Compression Styles: H.264 (MPEG-4, Part 10)/Motion JPEG (21 levels of quality)
  • Frame Rate: up to 14fps @ 2592 x 1944
  • WDR Technology: No
  • Image Settings: Programmable shutter speed to help control motion blur, Pixel Binning Mode, Flexible Cropping (resolution windowing down to 1x1 pixel for JPEG and 2x2 pixels for H.264), Low light noise filter control, Bit rate and bandwidth limitation control, Backlight compensation and multi-matrix white balance, 50/60Hz selectable flicker control, Electronic pan, tilt, zoom (PTZ) and image flip 180°, Programmable resolution, brightness, saturation, gamma, sharpness, tint
  • Privacy Mask: Yes
  • Built-in Microphone: Yes
  • Audio Capabilities: One-way listening via Audio out
  • Alarm/Event Management: On-camera motion detection and privacy mask w/1024 detection zones
  • ONVIF: No
  • Security: N/A
  • Users: N/A
  • On-board Storage: No
  • Indoor/Outdoor: Indoor
  • Housing/Enclosure Rating: None
  • Dimensions: Ø 5.1" (130mm) x 3.85" H (98mm)
  • Weight: 1.2 lb (0.54 kg)
  • Operating Temperature: -5°C (-23°F) to +50°C (122°F)
  • Operating Humidity: 0% to 90% (non-condensing)
  • Power/Consumption: PoE 802.3af, Class 2, 12–48V DC & 24V AC via terminal block / 5.7 Watts max
  • Warranty: 3 years
  • What's Included: Camera, in-ceiling mount, surface mount (preassembled on dome), O-ring (reassembled on bezel), dome cover, mounting template, CD with AV100 software and user manuals (license key required for recording), pack of three (3) screws and three (3) anchors

Arecont Vision AV5245DN-01-D Features

The AV5245DN-01-D MegaBall® 5-megapixel network camera is part of Arecont Vision’s full line of H.264 MegaBall® cameras. This fully-compliant implementation of H.264 (MPEG-4, Part 10) provides full 2592 (H) x 1944 (V) megapixel resolution at full video frame rates of 14 frames per second (fps). The AV5245DN-01-D camera line provides an all-in-one indoor 3" ball shape solution with integrated 5-megapixel camera, 0.98mm (Short axis) &1.12mm (Long axis) Panomorph Lens and dome mount enclosure. With the features of PSIA conformance, privacy masking, extended motion detection and flexible cropping, the AV5245DN-01-D is a high sensitivity, PoE (IEEE 802.3af) compliant day/night camera with black dome configurations. Built with Arecont Vision’s massively-parallel MegaVideo® processing technology, this camera offers more angular resolution in peripheral areas of a scene than conventional fisheye lenses.
