Replaced by the DGD8132
AVTECH AVZ8136 Features
- Camera Compatibility: TVI / CVI / Analog HD / 960H / IP Cameras (recommend AVTECH IP cameras for full capability)
- Maximum Number of Cameras/Channels: 32 channels of TVI / CVI / Analog HD / 960H video input + 4 IP channels
- Recording Rate: Analog Mode Up to 384 IPS @ 1920 x 1080 (32 channels); IP Mode UP to 60 IPS @ 1920 x 1080 (4 channels)
- Video Resolution: Analog Mode 1080P / 720P / QHD / 960H / Frame / Field / CIF; IP Mode 1920 x 1080 / 1280 x 720/ 640 x 480 / 320 x 240
- Compression Styles: H.264
- Event Notification: Push Video (9 channels) / Push Status / FTP / E-Mail
- Recording Mode: Manual / Timer / Motion / Alarm / Remote
- Pre-Alarm Recording: Yes
- Quick Search: Time / Motion / Alarm search mode
- Remote Access: EagleEyes on iOS & Android mobile devices
- Compatible Operating System: Windows & Mac
- Compatible Program: Web Browser: Windows Edge, Internet Explorer, Safari, Google Chrome & Mozilla Firefox; CMS Lite: 32CH central management software for Windows OS
- Ethernet: 1000 Base-T. Supports remote control and live view via Ethernet
- Hard Drive Bays: 8 bays
- Max TB per HD Bay: 10 TB (not included)
- Dimensions: 358mm(L) x 267mm(W) x 152mm(H)
- Weight: 5.9 kg (13 lb)
- Operating Temperature: 10℃ ~ 40℃ (50℉~104℉)
- Operating Humidity: 10% ~ 85%
- Power: 19V/4.7A
- Warranty: 2 years
- Please note: This unit has 1 LAN port. If connecting a switch for network cameras we recommend adding a switch with 2 or more uplink ports to connect to the DVR and to the network.
