AXIS M1113-E (0341-001) Network IP Camera

Discontinued, replaced by the MM1124-E.

AXIS M1113-E Features

• Resolution: 800x600 to 160x90
• Image Sensor: Progressive scan RGB CMOS 1/4”
• Day/Night: No
• Mechanical IR Cut Filter: No
• Minimum Illumination: 0.6 lux, F1.4
• IR Illuminators: No
• IR Illuminator Range: N/A
• Lens Type: Varifocal
• Focal Length: F1.4 2.9 - 8.2 mm
• Zoom: N/A
• Iris: Fixed
• Focus: N/A
• Field of View: 65° - 25° view
• Compression Styles: H.264 (MPEG-4 Part 10/AVC), Motion JPEG
• Frame Rate: 30 fps in all resolutions
• Image Settings: Compression, color, brightness, sharpness, contrast, white balance, exposure control, exposure zones, backlight compensation, fine tuning of behavior at low light, mirroring of images, Rotation – including Corridor Format, Text and image overlay, privacy mask
• Privacy Mask: Yes
• Built-in Microphone: No
• Audio Capabilities: N/A
• Alarm/Event Management: Video motion detection, active tampering alarm, Intelligent video; File upload: FTP, HTTP, network share and email; Notification: email, HTTP and TCP, Pre- and post-alarm video buffering
• ONVIF: Yes
• Security: Password protection, IP address filtering, HTTPS** encryption,
• digest authentication, user access log
• Users: N/A
• On-board Storage: No
• Indoor/Outdoor: Outdoor
• Housing/Enclosure Rating: IP66 Rating
• Dimensions without Sunshield: 109mm (W) x 258mm (L) x 82mm (H) (4.3" x 10.1" x 3.2") Stand: 204mm (8.0")
• Dimensions with Sunshield: 122mm (W) x 303mm (L) x 95mm (H) (3.7" x 11.9" x 4.8") Stand: 204mm (8.0")
• Weight: 780 g (1.72 lb.)
• Operating Temperature: -20 °C to 50 °C (-4 °F to 122 °F)
• Operating Humidity: 15 - 100% RH (condensing)
• Power: Power over Ethernet IEEE 802.3af Class 1
• Warranty: 1 Year
• What's Included: Wall bracket, sunshield, User’s Guide, CD with installation tools, recording software and Windows decoder 1-user license, Desiccant bag

AXIS M1113-E Overview

The AXIS M1113-E Network Camera has a CS-mount, varifocal, DC-iris lens and provides excellent image quality without motion blur using progressive scan at 30 frames per second in SVGA resolution. Multiple H.264 streams, as well as Motion JPEG streams, can be provided either in full frame rate or individually optimized for different quality needs and bandwidth constraints. The camera is easy to install outdoors thanks to Power over Ethernet support, a removable sunshield and a wall bracket. It has protection against dust, rain, snow and sun and the operating conditions ranges between -20°C to +50°C (-4 °F to 122 °F) and requires no additional heater. The casing is made of UV resistant polymer and requires no additional heater. Wall brackets and a removable sunshield are included in the package. Other mounting brackets are available as accessories.
