AXIS M1114-E (0342-001) HD Network IP Camera

Discontinued, replaced by the M1125-E.

AXIS M1114-E Features

• Resolution: 1280x800 to 160x90
• Image Sensor: Progressive scan RGB CMOS 1/4”
• Day/Night: No
• Mechanical IR Cut Filter: No
• Minimum Illumination: 0.6 lux, F1.2
• IR Illuminators: No
• IR Illuminator Range: N/A
• Lens Type: Varifocal
• Focal Length: 2.8 - 8 mm F1.2
• Zoom: N/A
• Iris: Fixed
• Focus: N/A
• Field of View: 77° - 29°
• Compression Styles: H.264 (MPEG-4 Part 10/AVC), Motion JPEG
• Frame Rate: 30 fps in all resolutions
• Image Settings: Compression, color, brightness, sharpness, contrast, white balance, exposure control, exposure zones, backlight compensation, fine tuning of behavior at low light, mirroring of images, Rotation – including Corridor Format, Text and image overlay, privacy mask
• Privacy Mask: Yes
• Built-in Microphone: No
• Audio Capabilities: N/A
• Alarm/Event Management: Video motion detection, active tampering alarm, Intelligent video; File upload: FTP, HTTP, network share and email; Notification: email, HTTP and TCP, Pre- and post-alarm video buffering
• ONVIF: Yes
• Security: Password protection, IP address filtering, HTTPS** encryption,
• digest authentication, user access log
• Users: N/A
• On-board Storage: No
• Indoor/Outdoor: Outdoor
• Housing/Enclosure Rating: IP66 Rated
• Dimensions without Sunshield: 109mm (W) x 258mm (L) x 82mm (H) (4.3" x 10.1" x 3.2") Stand: 204mm (8.0")
• Dimensions with Sunshield: 122mm (W) x 303mm (L) x 95mm (H) (3.7" x 11.9" x 4.8") Stand: 204mm (8.0")
• Weight: 790 g (1.74 lb.)
• Operating Temperature: -20 °C to 50 °C (-4 °F to 122 °F)
• Operating Humidity: 15 - 100% RH (condensing)
• Power: Power over Ethernet IEEE 802.3af Class 1
• Warranty: 1 Year
• What's Included: Stand, Installation Guide, CD with installation tools, recording software and User’s Manual, Windows decoder 1-user license
