Sale price$349.00
SKU: M3014 (0285-001)

Replaced by: AXIS M3015 (01151-001)


AXIS M3014 Features

  • Resolution: 640x480 to 160x120
  • Image Sensor: AXIS M3014: 1/4” Progressive scan RGB CMOS 1 Megapixel
  • Day/Night: No
  • Mechanical IR Cut Filter: No
  • Minimum Illumination: 1 - 100000 lux, F2.0
  • IR Illuminators: No
  • IR Illuminator Range: N/A
  • Lens Type: Fixed
  • Focal Length: 2.8 mm, F2.0
  • Zoom: N/A
  • Iris: Fixed
  • Focus: N/A
  • Field of View: 80°
  • Compression Styles: H.264 (MPEG-4 Part 10/AVC), Motion JPEG
  • Frame Rate: 30 fps
  • Image Settings: Compression, color, brightness, sharpness, contrast, white, balance, exposure control, exposure zones, backlight, compensation, fine tuning of behavior at low light, rotation, Text and image overlay, Privacy mask, Mirroring of Images
  • Privacy Mask: Yes
  • Built-in Microphone: No
  • Audio Capabilities: N/A
  • Alarm/Event Management: Video motion detection, active tampering alarm, Intelligent video, File upload via FTP, HTTP and email, Notification via email, HTTP and TCP, Pre- and post-alarm video buffering
  • ONVIF: Yes
  • Security: Password protection, IP address filtering, HTTPS* encryption, IEEE 802.1X network access control, digest authentication, user access log
  • Users: N/A
  • On-board Storage: N/A
  • Indoor/Outdoor: Indoor
  • Housing/Enclosure Rating: N/A
  • Dimensions: Radius: 91.6 mm (3.6"); Dome Height: 27.8mm (1.1"); In-Ceiling Mount Height: 27.8mm (1.1"); In-Ceiling Mount Radius: 70.0mm (2.8"); Possible Ceiling Thickness: 1-80mm (0.1-3.1")
  • Weight: 260 g (0.6 lb.)
  • Operating Temperature: 0 ºC – 45 ºC (32 ºF – 113 ºF)
  • Operating Humidity: Humidity 20 - 80% RH (non-condensing)
  • Power: Power over Ethernet IEEE 802.3af Class 1
  • Warranty: 1 Year
  • What's Included: Installation Guide, CD with installation tools, recording software and User’s Manual, Windows decoder 1-user license (mid-span not included)

AXIS M3014 Overview

The AXIS M3014 (0285-001) fixed dome network camera is designed to be installed in dropped ceilings, using a recessed mounting design, this camera can be mounted to present only a 3cm profile from the ceiling. The camera is very small in total size, having a diameter of only 9cm. This ultra-compact design does not prevent the camera from delivering where security is concerned. The AXIS M3014 fixed dome network camera makes use of the latest streaming and compression formats to maximize network efficiency while preserving image clarity. The AXIS M3014 fixed dome network camera can stream in the H.264 format. This allows the camera to consume very little bandwidth while still delivering very crisp images. The camera can also use the Motion JPEG format, if needed. The H.264 format can be altered to suit the action in the area being monitored. During times of low or no activity, the bit rate of the stream is automatically reduced to preserve network bandwidth. The AXIS M3014 fixed dome network camera delivers 1.3 megapixel quality images, ensuring that every detail is captured. The AXIS M3014 fixed dome network camera is destined to be easy to install. The camera can be powered directly from its Ethernet connection. Using Power over Ethernet (PoE) technology, the need to locate electrical sockets or other hardware to power the camera is eliminated. This reduces installation costs considerably. The ultra-compact design makes this camera perfect for offices and homes.
