AXIS M3203 (0336-001) Fixed Dome Network IP Camera

Discontinued.

AXIS M3203 Features

• Resolution: 800x600 to 160x90
• Image Sensor: 1/4” progressive scan RGB CMOS
• Day/Night: No
• Mechanical IR Cut Filter: No
• Minimum Illumination: 0.9 - 100000 lux, F1.7
• IR Illuminators: Yes
• IR Illuminator Range: N/A
• Lens Type: Varifocal
• Focal Length: 2.8 - 10 mm F1.7
• Zoom: N/A
• Iris: Fixed
• Focus: N/A
• Field of View: 66° - 18° view
• Compression Styles: H.264 (MPEG-4 Part 10/AVC) Motion JPEG
• Frame Rate: 30 fps in all resolutions
• Image Settings: Compression, color, brightness, sharpness, contrast, white balance, exposure control, exposure zones, backlight compensation, fine tuning of behavior at low light, mirroring of images, Rotation – including Corridor Format, Text and image overlay, privacy mask
• Privacy Mask: Yes
• Built-in Microphone: No
• Audio Capabilities: N/A
• Alarm/Event Management: Video motion detection, active tampering alarm, Support for AXIS Camera Application Platform enabling, installation of additional applications, Intelligent video, File upload: FTP, HTTP, network share and email; notification: email, HTTP and TCP; external output activation; video recording to edge storage; pre- and post-alarm video buffering
• ONVIF: Yes
• Security: Password protection, IP address filtering, HTTPS** encryption, digest authentication, user access log
• Users: N/A
• On-board Storage: No
• Indoor/Outdoor: Indoor
• Housing/Enclosure Rating: N/A
• Dimensions: 94 x 144 x 132 mm (3.7'' x 5.7'' x 5.2'')
• Weight: 430 g (1.0 lb.)
• Operating Temperature: 0 °C to 50 °C (32 °F to 122 °F)
• Operating Humidity: Humidity 15 - 85% RH (non-condensing)
• Power: Power over Ethernet IEEE 802.3af Class 2 (max. 4.2 W)
• Warranty: 3 Years
• What's Included: Installation Guide, Installation and Management Software CD, key for tamper-proof screws, Windows decoder 1-user license
• Notes: N/A

AXIS M3203 Overview

The AXIS M3203 (0336-001) network camera is ideal for situations where discreet surveillance is required. This camera is provided with a fixed dome that protects the unit and improves its aesthetics. The AXIS M3203 network camera is also provided with advanced imaging technology that ensures an excellent image in trying conditions. The camera is also resistant to attempts to tamper with the device, providing another layer of security. The AXIS M3203 network camera is also compatible with some of the most advanced networking protocols and technologies.
The AXIS M3203 network camera captures images in SVGA resolution. It can transmit two streams simultaneously in the H.264 format. This format can accommodate network traffic management by reducing bandwidth in times when little action is going on in front of the camera. The camera can also transmit in the popular Motion JPEG format. This camera is provided with a pixel counter, which can be used to ensure that the image is up to standards for various applications.
The AXIS M3203 network camera can be powered directly over the Ethernet. Power over Ethernet (PoE) technology simplifies the installation process and reduces installation costs by eliminating the need to have a separate power source installed for the device. The camera is easy to mount. The lens can be directed at any part of the scene desired. The camera also detects attempts at tampering or attempts to obscure the image.
