AXIS
AXIS P1405-LE (0621-001) 2MP Compact HD Bullet Network Camera
Replaced by: AXIS P1405-LE Mk II (0961-001)
AXIS P1405-LE Features
- Max Resolution: 1920x1080
- Image Sensor: 1/2.8” progressive scan CMOS
- Day/Night: Yes
- Mechanical IR Cut Filter: Yes
- Minimum Illumination: Color: 0.35 lux at F1.6, B/W: 0.07 lux at F1.6
- IR Illuminators: Yes
- IR Illuminator Range: Up to 10 m (33 ft)
- Lens Type: Varifocal
- Focal Length: f=2.8-10 mm / F1.6
- Zoom: Digital PTZ, Remote zoom (3-3.5x)
- Iris: P-iris
- Focus: Autofocus & remote focus
- Field of View: Horizontal angle of view: 34˚ – 93˚ view
- Compression Styles: H.264 Main and Baseline profiles (MPEG-4 Part 10/AVC), Motion JPEG
- Frame Rate: Up to 25/30 fps (50/60 Hz) in all resolutions
- WDR Technology: Yes
- Image Settings: Manual shutter time, Compression, Color, Brightness, Sharpness, White balance, Exposure control, Exposure zones, Backlight compensation, Fine tuning of behavior at low light, Text and image overlay, Privacy masks, Rotation: 0°, 90°, 180°, 270°, including Corridor Format
- Privacy Mask: Yes
- Built-in Microphone: No
- Audio Capabilities: None
- Alarm/Event Management: Detectors: Day/Night Mode, Live Stream Accessed Tampering; Hardware: Network, Temperature; Input Signal: Manual Trigger, Virtual Inputs; Storage: Disruption, Recording; System: System Ready; Time: Use Schedule, Recurrences; File upload via FTP, HTTP and email; Notification via email, HTTP and TCP; Video recording to edge storage, day/night mode; 40 MB Pre- and post-alarm video buffering
- ONVIF: Yes
- Security: Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X network access control, digest authentication, user access log
- Users: N/A
- On-board Storage: MicroSD slot supporting memory card up to 64 GB (card not included)
- Indoor/Outdoor: Outdoor
- Housing/Enclosure Rating: IP66- and NEMA 4X-rated, polyester polycarbonate blend
- Dimensions: Ø90 mm x 260 mm (3.5" x 10.2")
- Weight: 787 g (1.73 lb)
- Operating Temperature: -10 °C to 50 °C (14 °F to 122 °F)
- Operating Humidity: 10 - 100% RH (condensing)
- Power: Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3 / max 11.2 W
- Warranty: 3 Years
- What's Included: Camera, Mounting bracket, Weather shield, Drill template, Installation Guide, Installation and Management Software CD, Windows decoder 1-user license
AXIS P1405-LE Overview
AXIS P1405-LE with varifocal, P-iris lens provides excellent image quality at 30 frames per second in 2 megapixel / HDTV resolution. The P-iris control provides optimal depth of field, resolution, image contrast and clarity. The cost-effective, compactly designed camera offers multiple H.264 and Motion JPEG streams that can be individually optimized for bandwidth and storage efficiency. AXIS P1405-LE offers discreet integration of power efficient IR LED, the cameras provide automatic illumination of a scene in complete darkness, at an event or when requested by a user. The IR LED illumination, which is invisible to the human eye, is perfect for discovering objects in a range of up to 10 meters (33 ft). AXIS P1405-LE offers support for edge storage that allows recording video directly to a storage such as an microSD/SDHC card, thereby creating a flexible and reliable video surveillance system. AXIS P1405-LE has a compact low weight casing and integrated bracket for wall or ceiling mount. To further simplify installation, a wide range of mounting accessories are available. AXIS P1405-LE offers easy installation with remote zoom and focus for fine tuning of the picture from a computer as opposed to at the camera itself. Furthermore, the pixel counter assures that the required pixel resolution is met. In addition, the camera supports corridor format which allows you to get a vertically oriented, "portrait"-shaped video stream for effective monitoring of narrow areas. Power over Ethernet supplies power to the cameras via the network, which eliminates the need for power cables and reducing installation costs.
