Discontinued - Recommended Replacement 6AL445XANR
Features
Camera
- Image Sensor 1/2.8-in. STARVIS™ CMOS
- Effective Pixels 1920(H) x 1080(V), 2 MP
- RAM/ROM 1024 MB / 128 MB
- Scanning System Progressive
- Electronic Shutter Speed 1/1 s to 1/30,000 s
- Minimum Illumination Color: 0.005 Lux at F1.6, 0 Lux with IR on
- S/N Ratio More than 56 dB
- IR Distance Distance up to 550 m (1804.46 ft)
- IR On/Off Control Auto, Manual
- IR LEDs Laser Module
Lens
- Focal Length 3.95 mm to 177.7 mm
- Max. Aperture F1.6 to F4.95
- Angle of View Horizontal: 70.3° to 1.8°
- Optical Zoom 45x
- Focus Control Auto, Manual
- Close Focus Distance 100 mm to 1000 mm
PTZ
- Pan/Tilt Range
- Pan: 0° to 360° endless
- Tilt: –20° to 90°,
- Auto Flip 180°
- Manual Control Speed Pan: 0.1° to 200° /s
- Tilt: 0.1° to 120° /s
- Preset Speed Pan: 240° /s;
- Tilt: 200° /s
- Presets 300
- PTZ Mode 5 Pattern, 8 Tour, Auto Pan ,Auto Scan
- Speed Setup Human-oriented focal Length/ speed adaptation
- Power up Action Auto restore to previous PTZ and lens status after power failure
- Idle Motion Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period
- Protocol DH-SD, Pelco-P/D (Auto recognition)
Video
- Compression Smart H.265+, H.265, Smart H.264+, H.264
- Streaming Capability Three (3) Streams
- Resolution 1080p (1920 x 1080), 1.3 MP (1280 x 960), 720p (1280 x 720), D1 (704 x 380), CIF (352 x 240)
- Frame Rate Main Stream 1080p, 1.3 MP or 720p at 60 fps, Sub Stream 1 D1, CIF at 30 fps, Sub Stream 2 1080p, 1.3 MP, 720p, D1, or CIF at 30 fps
- Bit Rate Control CBR, VBR
- Bit Rate H.265 / H.264: 448 K to 8192 Kbps,
- Day/Night Auto (ICR), Color, B/W
- Backlight Compensation BLC, HLC, True WDR (120 dB)
- White Balance Auto, ATW, Indoor, Outdoor, Manual
- Gain Control Auto, Manual
- Noise Reduction Ultra DNR (2D/3D)
- Advanced Features Motion Detection, Region of Interest,
- Electronic Image Stabilization (EIS), Defog
- Digital Zoom 16x
- Flip 180°
- Privacy Masking Up to 24 areas
Audio
- Compression G.711a, G.711Mu, AAC, G.722, G.726, G.729, MPEG2-L2
Network
- Ethernet RJ45 (1000 Base-T/100 Base-TX)
- Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x
- Interoperability ONVIF, PSIA, CGI
- Streaming Method Unicast / Multicast
- Max. User Access 20 users
- Edge Storage
- NAS (Network Attached Storage)
- Local PC for instant recording
- Micro SD Car, maximum 128 GB
- Web Viewer IE 10, Firefox, Safari
- Management Software Smart PSS, DSS
- Mobile Operating System IOS, Android
- Certifications CE, EN55032, EN55024, EN50130-4
- Electromagnetic Compatibility (EMC) FCC Part 15 Subpart B, ANSI C63.4- 2014
Interface
- Video Interface One (1) BNC (1.0 Vp-p, 75 Ω)
- Audio Interface Input: One (1) Channel
- Output: One (1) Channel
- RS485 One (1)
- Alarm Input: Seven (7) Channels, Output: Two (2) Channels
Electrical
- Power Supply 24 VAC, 3 A (± 25%), Hi-PoE
- Power Consumption 24 W, 38 W with IR on
