Discontinued - Recommended Replacement A51BJ02
Features
Camera
- Image Sensor 1/2.7-in. CMOS
- Effective Pixels 2592 (H) x 1944 (V), 5 MP
- Scanning System Progressive
- Electronic Shutter Speed 1/30 s to 1/100000 s
- Minimum Illumination Color: 0.02 Lux at F1.85 (30 IRE), 0 Lux with IR on
- S/N Ratio More than 65 dB
- IR Distance Up to 30 m (98.04 ft)
- IR On/Off Control Auto, Manual
- IR LEDs 12
Lens
- Lens Type Fixed Lens / Fixed Iris
- Mount Type Board-in
- Focal Length 2.8 mm
- Max Aperture F1.85
- Horizontal Angle of View 103°
- Close Focus Distance 900 mm (35.43 in.)
Video
- Resolution 5 MP (2592 x 1944)
- Frame Rate 5 MP at 20 fps, 4 MP at 30 fps, 1080p at 30 fps
- Video Output One (1) BNC HDCVI High-definition Channel or One (1) BNC CVBS, AHD or TVI Channel, switchable
- Day/Night Auto (ICR), Manual
- OSD Menu Multi-language
- BLC Mode BLC, HLC, DWDR
- WDR Digital WDR
- Gain Control AGC
- Noise Reduction 2D
- White Balance Auto, Manual
- Smart IR Auto, Manual
Certifications
- Safety EN55032, EN55024, EN50130-4, UL60950-1+CAN/CSA C22.2 No.60950-1
- Electromagnetic Compatibility (EMC) FCC CFR 47 FCC Part 15 Subpart B, ANSI C63.4-2014
Electrical
- Power Supply 12 VDC ±30%
- Power Consumption Maximum 3.6 W (12 VDC with IR on)
Environmental
- Operating Conditions –40° C to +60° C (–40° F to +140° F), Less than 95% RH
- Storage Conditions ––40° C to +60° C (–40° F to +140° F), Less than 95% RH
- Ingress Protection IP67
Construction
- Casing Aluminium
- Dimensions ø93.40 mm × 79.40 mm (ø3.68 in. x 3.13 in.)
- Net Weight 0.28 kg (0.62 lb)
- Gross Weight 0.38 kg (0.84 lb)
