Discontinued – Recommended Replacement: A52BL62
Features
Camera
- Image Sensor 1/2.8-in. STARVIS™ CMOS Sensor
- Effective Pixels 2592 (H) x 1944 (V), 5 MP
- Scanning System Progressive
- Electronic Shutter Speed 1/3 s to 1/100,000 s
- Minimum Illumination Color: 0.005 lux at F1.6, 30 IRE, 0 lux with IR on
- S/N Ratio More than 65 dB
- IR Distance Up to 30.0 m (98.43 ft)
- IR On/Off Control Auto, Manual
- IR LEDs 12
Lens
- Lens Type Fixed Lens, Fixed Iris
- Mount Type Board-in
- Focal Length 2.8 mm
- Maximum Aperture F1.6
- Angle of View Horizontal: 98°
- Close Focus Distance 800 mm (31.50 in.)
Certifications
- CE EN55032, EN55024, EN50130-4
- Safety UL60950-1, CAN/CSA C22.2 No.60950-1
- Electromagnetic Compatibility (EMC) FCC CFR 47 Part 15 subpart B, ANSI C63.4-2014
Interface
- Audio Input: One (1) Channel, RCA Jack
Electrical
- Power Supply 12 VDC ± 30%
- Power Consumption Maximum 5.3 W (12 VDC, IR on)
Environmental
- Operating Conditions –40° C to +60° C (–40° F to +140° F), Less than 90% RH
- Storage Conditions –40° C to +60° C (–40° F to +140° F), Less than 90% RH
- Ingress Protection IP67
- Vandal Resistance IK10
Construction
- Casing Aluminium
- Dimensions ø109.90 mm x 81.0 mm (ø4.33 in. x 3.19 in.)
- Net Weight 0.33 kg (0.73 lb)
- Gross Weight 0.45 kg (0.99 lb)
