Dahua DH-A24-3A Features
Electrical
- Input 120 VAC, 60 Hz
- Output 24 VAC (±5%), 3A
- Has spliced ends for terminal block connection
Environmental
- Operating Temperature –10 °C to +40° F (14 °F to 104 °F)
- Storage Temperature –5 °C to +60° F (23 °F to 140 °F)
- Operating Humidity 30% to 85%, Relative
Physical Properties
- Weight 1645 g (3.63 lb)
- Dimensions (L x W x H) 120.0 mm x 80.0 mm x 65.0 mm (4.72 in. x 3.15 in. x 2.56 in.)
- Installation Mode Plane Installation
- Color Black
- Input Plug 2-pin North American Plug
- Cord Lengths Input: 1 m (3.28 ft)
- Output: AWG18 x 2C; 1.83 m (6.0 ft)
Certifications
- Safety CE, UL, SAA
