Features
General
- Input voltage 24 VDC to 36 VDC
- Provides 12 VDC, 8 W Power Supply to Remote Cameras
- Real-time Video Transmission without Delay or Interference.
- Transmission distance: 300 m (1312 ft)
- Transmit one-channel HD Video and one channel DC Power over a UTP (CAT-5E or CAT-6) Cable
- Surge Protection and Anti-interference Protection
- RJ45 Standard Connection
- Two (2) Baluns Included
Video
- Transmission Signal One (1) Channel
- Transmission Distance, maximum HDCVI 720p: 400 m (1312.34 ft); 1080p: 250 m (820.21 ft); 4 MP: 200 m (656.17 ft)
- Category Type UTP CAT 5E/6
Video Transmission Properties and Ports
- Coaxial Video Connector BNC-M
- Connection RJ45
- Compatible Format HDCVI, AHD, TVI, CVBS
- Resolution 720p, 1080p, 4 MP
- Anti-interference > 60 dB
Protection
- ESD 1a contact discharge electricity level 3, 1b air discharge electricity level 3, Per: IEC61000-4-2
- Coaxial Cable Connector 2 KV (common-code) per IEC1000-4-5
- UTP Cable Connector 2 KV (different-code), 4 KV (common-code), per IEC1000-4-5
Impedance
- BNC Male 75 Ω
- UTP Cable 100 Ω
Physical Properties
- Dimensions 72.60 mm x 42.50 mm x 24.50 mm (2.86 in. x 1.67 in. x 0.96 in.)
- Shell ABS
- Color Black
- Net Weight 66.40 g (0.15 lb)
Stability
- MTBF > 10000 h
Environmental
- Operating Temperature –10 °C to +55 °C (14 °F to 131 °F)
- Storage Temperature –20 °C to +70 °C (–4 °F to 158 °F)
- Humidity 0 to 95%, non-condensing
