Features
Camera
- Image Sensor 1/2.8-in. 2 MP STARVIS™ CMOS
- Effective Pixels 1920(H) x 1080(V)
- Scanning System Progressive
- Electronic Shutter Speed 1/50 s to 1/10000 s
- Minimum Illumination Color: 0.005 lux at F1.6, 0 lux at F1.6 (IR on)
- S/N Ratio More than 50 dB
- IR Distance 3.0 m to 8.0 m (9.84 ft to 26.25 ft)
- IR On/Off Control Auto, Manual
- IR LEDs Four (4)
Lens
- Lens Type Motorized / Auto Iris (DC)
- Mount Type Board-in
- Focal Length 2.7 mm to 12 mm
- Max. Aperture F1.6
- Angle of View Horizontal: 101° to 36°, Vertical: 53° to 20°
- Optical Zoom 5x
- Focus Control Auto
- Close Focus Distance 3.0 m to 8.0 m (9.84 ft to 26.25 ft)
- Focus Width Range 3.50 m (11. 48 ft), approximately one (1) lane
Video
- Compression H.265, H.264M, H.264H, H.264B, MJPEG
- Streaming Capability Two (2) Streams
- Resolution 1080p (1920 x 1080), 720p (1280 x 720), D1 (704 x 576)
- Frame Rate Main Stream: 1080p at 30 fps, Sub Stream: 720p or D1 at 30 fps
- Bit Rate Control CBR, VBR
- Bit Rate 32 Kbps to 16384 Kbps
- Day/Night Auto (ICR), Color, B/W
- BLC Mode BLC, HLC, Ultra WDR (140 dB)
- White Balance Auto, Manual
- Gain Control Auto, Manual
- Noise Reduction 3D
Network
- Ethernet RJ-45 (100/1000 Base-T)
- Protocol IPv4/IPv6, HTTP, TCP/IP, UDP, NTP, DHCP, DNS
- Interoperability ONVIF, CGI
- Streaming Method Unicast, Multicast
- Maximum User Access 20 Users
- Edge Storage Local PC for instant recording
- Micro SD Card Slot, 64 GB maximum
- Web Viewer IE, Chrome
- Management Software DSS
Certifications
- Safety UL60950-1
- Electromagnetic Compatibility (EMC) FCC CFR 47 Part 15 Subpart B
Interface
- Audio Input: One (1) Channel, Output: One (1) Channel
- Alarm Input: Two (2) Channels, Output: One (1) Channel
Electrical
- Power Supply 12 VDC or PoE (IEEE802.3af Class 0)
- Power Consumption 12 W, with IR on and motorized lens engaged
Environmental
- Operating Temperature –40° C to +60° C (–40° F to +140° F), Less than 95% RH
- Storage Temperature –40° C to +60° C (–40° F to +140° F), Less than 95% RH
- Ingress Protection IP67
- Vandal Resistance IK10
Construction
- Casing Metal
- Dimensions 273.20 mm x 95.0 mm x 96.40 mm (10.76 in. x 3.74 in. x 3.79 in.)
- Net Weight 1.12 kg (2.47 lb)
- Gross Weight 1.52 kg (3.35 lb)
Please note: does not include License Plate Recognition software. Please consult Datasheet for optimal camera placement.
