Exacq
Exacq S-12T-2U-2 Rackmount 2U storage server, 1,500Mbps archiving rate (2,000Mbps with optional quad NIC)
Quantity:
Archive Video and Audio to S-Series with Instant Search Capability
- Increase recoverability with backup from exacqVision recorders to S-Series storage
- Optimize network load with scheduled or continuous archiving
- Store critical video and audio longer with flexible, user-defined archiving rules
- Consolidate video archives from multiple video recorders on one or more S-Series
- Optional dual 10 Gbps network interfaces for fastest archiving or mass client performance
Extend exacqVision video storage to store more cameras or more days without additional video recorders
- Easily expand primary video recorder storage without complicated third-party storage
- Lower cost and greater flexibility with shared network storage compared to external storage on multiple recorders
Unified VMS Solution
- Reduce the complexity and cost of integrating disparate solutions with a complete exacqVision recorder and storage solution.
- No need to learn multiple systems to administer and monitor storage and recorders. Configure and monitor health from the same intuitive exacqVision client interface.
- Complete VMS support from Exacq Technologies
Expandable and High Reliability Storage
- Expandable to 240TB with additional drives
- Fault tolerant of hard drive or power source failure with S-Series Enterprise RAID 5/6 and redundant power supplies
- Maximize hard drive reliability with enterprise-class hard drives
- Hot spare drive options for automatic replacement of failed drive
- Optional RAID protected operating system drives guarantee high availability, maximizing system up-time
- Add optional annual on-site video recorder repair service to diagnose and resolve issues faster within the continental United States
 |
 |
|
| Specifications | S-Series Enterprise 2U | S-Series Enterprise 4U |
| Maximum Video Recorders | 32 | 64 |
| Maximum Storage | 96 TB | 240 TB |
| Maximum Hard Drives | 8 | 20 |
| Maximum Data Rate | 1,500 Mbps with dual NIC bonding 2,000 Mbps (optional tri NIC Bonding) |
1,500 Mbps with dual NIC bonding 2,000 Mbps (optional tri NIC Bonding) |
| Operating System | Linux Ubuntu 20.04 | Linux Ubuntu 20.04 |
| RAID | RAID 5 (Included) | RAID 6 (Included) |
| CPU | Intel Core i3 Intel Xeon W (Optional) |
Intel Core i3 Intel Xeon W (Optional) |
| RAM | 8 GB 16 GB (Optional) |
8 GB 16 GB (Optional) |
| Operating System Drive | 256 GB SSD | 256 GB SSD |
| Monitor Output | DisplayPort, HDMI, VGA 3 Simultaneous |
DisplayPort, HDMI, VGA 3 Simultaneous |
| NIC | 1 x 2.5 Gbps, 1 x 1 Gbps 3 x 1 Gbps, 1 x 2.5 Gbps (Optional) 2x 10 Gbps SPF+, 1 x 2.5 Gbps, 1 x 1 Gbps (Optional) |
1 x 2.5 Gbps, 1 x 1 Gbps 3 x 1 Gbps, 1 x 2.5 Gbps (Optional) 2x 10 Gbps SPF+, 1 x 2.5 Gbps, 1 x 1 Gbps (Optional) |
| USB | 2 x USB 3.2, 4 x USB 3.1, 2 x USB 2.0 | 2 x USB 3.2, 4 x USB 3.1, 2 x USB 2.0 |
| Alarm Inputs | 4 | 8 |
| Alarm Outputs | 1 TTL, 1 Relay | 3 TTL, 1 Relay |
| Audio Outputs | 4 | 4 |
| DVD | External (Optional) | External (Optional) |
| Accessories | Keyboard, Mouse | Keyboard, Mouse |
| Dimensions (H x W x D) | 3.5 x 17 x 24 in 8.9 x 43.18 x 60.96 cm |
7.0 x 16.875 x 27 in 17.8 x 42.9 x 68.6 cm |
| Weight | 34 - 50 lbs 15.4 - 22.7 kg |
49 - 90 lbs 22.3 - 40.9 kg |
| Regulatory |  |
|
| Input Voltage | 120/240 VAC auto-sensing |
120/240 VAC auto-sensing |
| Power Supplies | Redundant | Redundant |
| Power & Heat | 240 Watts/790 BTU/h (Max) 170 Watts/570 BTU/h (Typical) |
390 Watts/1320 BTU/h (Max) 210 Watts/700 BTU/h (Typical) |
| Operating Temperature | 40° - 95°F 4.5° - 35°C |
40° - 95°F 4.5° - 35°C |
| Warranty | 3 Years | 3 Years |
Rackmount 2U storage server, 1,500Mbps archiving rate (2,000Mbps with optional quad NIC), 350Mbps extended storage rate, 8 drive bays max 96TB, RAID 5, triple Gb NIC, Ubuntu Linux 20.04, exacqVision storage software pre-installed, keyboard & mouse, 3 year hardware warranty and software updates.
