Hanwha PRN-4011 Features
- Operating System: Linux
- Camera Compatibility: Hanwha & ONVIF-compatible cameras
- Maximum Number of Cameras/Channels: Up to 64CH
- Recording Bandwidth: Max. 400Mbps (RAID-5/6)
- Compression Styles: H.265, H.264, MJPEG, WiseStream (H.265, H.264)
- Display Layout: [Local monitor] 1 / 2V / 3V / 4 / 9 / 16 / 25 / 36 /64/ Sequence, [Web] 1 / 4 / 9 / 16 / 25 / 36 / 64/Sequence
- Event Notification: E-mail, PTZ preset, Alarm out, Buzzer, Monitor out
- Alarm & Event Management: Alarm input, Video loss, Camera event(Sensor, MD, Video analytics, Defocus)
- Scheduled Recording: Yes
- Event Recording: Yes
- Manual Recording: Yes
- Recording Frame Rate: CIF ~ 12MP
- Remote Access with PC Based Web Browser: Yes
- Mobile App Support: iPOLiS mobile viewer for iOS & Android
- Playback Features: Date & Time(Calendar)/Event log list / Text search / Smart search
- Hard Drive Bays: 12 x 3.5" HDD
- Max TB per HD Bay: 8 TB
- USB Ports: 2, both on the front
- Ethernet Ports: RJ-45 4ea (LAN/WAN, 1Gbps), 1000M SFP 2ea
- Display Port(s): 1 x HDMI, 1 x VGA
- PoE Ports: None
- Dimensions (W x H x D): 436.0 x 132.0 x 450.0mm (17.17" x 5.2" x 17.72") (3U)
- Weight: Approx. 11Kg (24.3 lb, HDD not included)
- Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F)
- Operating Humidity: 20 ~ 85% RH
- Power Source / Consumption: 100 ~ 240 VAC ±10%; 50/60 Hz, 3~1.5A (Dual SMPS) / Max. 250W (853 BTU with HDD 12ea)
- Warranty: 3 years
- Please note: higher HD storage options are available, please contact us directly for pricing.
Hanwha PRN-4011 Overview
Hanwha’s PRN-4011 is a 64CH network video recorder that will allow the connection of up to 64 cameras with up to 12MP resolution each, triple codec recording and playback H.265/H.264/MJPEG, dual monitor output, 4K HDMI output, 12 hot swap hard disc drives and redundant power supplies. While supporting high level functions such as RAID 5/6, Four gigabit ethernet ports and advanced video motion detection, it also supports a local monitor for ease of use, automatic camera registration, ONVIF cameras and mobile apps for smart phone and tablet connectivity.
