Hanwha / Samsung
Hanwha XNP-8250R - 6MP Network 25x IR PTZ Camera
• Max. 6MP resolution
• 5~125mm (25x) optical zoom (digital 32x, total 800x zoom)
• Max. IR viewable length 200m (Wise IR)
• Day & Night (ICR), extreme WDR (120dB), DIS (Built-in gyro sensor)
• Intelligent Analytics, Object auto tracking (Person/Vehicle), Target lock tracking
• H.264, H.265, MJPEG codec, WiseStreamII
• IP66, IK10, NEMA4X, NEMA-TS 2 (2.2.8, 2.2.9)
• PTZ PLUS Design applied (Compact, Lighter, Simple cabling)
Product Spec
-
Video Imaging Device 1/2.8" CMOS Resolution 3328x1872, 3072x1728, 2592x1944, 2688x1520, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720,
1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240Max. Framerate H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 30fps/25fps(60Hz/50Hz)Min. Illumination Color: 0.1Lux(F1.6, 1/30sec)
BW: 0Lux(IR LED On)Lens Focal Length (Zoom Ratio) 5~125mm(25x) zoom (digital 32x, total 800x zoom) Max. Aperture Ratio F1.6(Wide)~F3.73(Tele) Angular Field of View H: 57.42°(Wide)~2.71°(Tele) / V: 33.54°(Wide)~1.55°(Tele) Min. Object Distance 3m(9.84ft) Focus Control Oneshot AF, Focus save Lens Type DC auto iris Pan / Tilt / Rotate Pan Range 360° Endless Pan Speed Max. 700°/sec, Manual: 0.024°/sec~250°/sec Tilt Range 110°(-20°~90°) Tilt Speed Max. 500°/sec, Manual: 0.024°/sec~250°/sec Sequence Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule Preset Accuracy Up to '±0.1°, Pan/Tilt correction Operational Camera Title Displayed up to 85 characters Direction Indicator Support Day & Night Auto(ICR)/Color/BW/Schedule Backlight Compensation BLC, HLC, WDR, SSDR Wide Dynamic Range Extreme WDR(120dB) Digital Noise Reduction SSNRⅤ Digital Image Stabilization Support(built-in gyro sensor) Defog Support Motion Detection 8ea, 8point polygonal zones Privacy Masking 32ea, polygonal Support
- Color: Grey/Green/Red/Blue/Black/White
- MosaicGain Control Low / Middle / High White Balance ATW / AWC / Manual / Indoor / Outdoor Electronic Shutter Speed Minimum / Maximum / Anti flicker (2~1/12,000sec) Video Rotation Flip, Mirror Analytics Directional detection, Fog detection, Face detection, Motion detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Shock detection
* Audio detection, Sound classification(with NW I/O Box)Alarm Triggers Analytics, Network disconnect
* Alarm input(with NW I/O Box)Alarm Events File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
PTZ Preset
Handover
* Alarm output(with NW I/O Box)Water Removal Support(Spinning dry) Auto Tracking Object auto tracking(Person/Vehicle), Target lock tracking Network Ethernet Metal shielded RJ-45(10/100BASE-T) Video Compression H.265/H.264: Main/Baseline/High, MJPEG Smart Codec Manual(5ea area), WiseStreamⅡ Bitrate Control H.264/H.265: CBR or VBR
MJPEG: VBRStreaming Unicast(20 users) / Multicast (128 user)
Multiple streaming(Up to 10 profiles)Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour,LLDP, SRTP Security HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP)
Device certificate(Hanwha Techwin Root CA)Application Programming Interface ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platformGeneral Webpage Language English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,
Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, GreekEdge Storage Micro SD/SDHC/SDXC 2slot 1TB Memory 4GB RAM, 512MB Flash Environmental & Electrical Operating Temperature / Humidity -40°C~+60°C(-40°F ~ +140°F) / Less than 95% RH(Non-condensing)
Maximum Temperature based on NEMA-TS 2(2.2.7) : +74°C(+165°F)Storage Temperature / Humidity -50°C~+60°C (-58°F~+140°F) / Less than 95% RH(Non-condensing) Certification IP66, IK10, NEMA4X, NEMA-TS 2(2.2.8, 2.2.9) Input Voltage HPoE(IEEE802.3bt, Class6, Type3, Injector included) Power Consumption Typical 20W, Max 40W Mechanical Color / Material Body : White / Aluminum
Head : Black / Polycarbontate
Hard-coated domeRAL Code White: RAL9003 / Black: RAL9005 Product Dimensions / Weight Ø158x293.3mm(6.22x11.55") / 3.2Kg(7.05lb) DORI (EN62676-4 standard) Detect (25PPM/ 8PPF) Wide: 121.5m(398.7ft) / Tele: 2813.9m(9232.1ft) Observe (63PPM/ 19PPF) Wide: 48.6m(159.5ft)/ Tele: 1125.6m(3692.8ft) Recognize (125PPM/ 38PPF) Wide: 24.3m(79.7ft)/ Tele: 562.8m(1846.4ft) Identify (250PPM/ 76PPF) Wide: 12.2m(39.9ft) / Tele: 281.4m(923.2ft)
