- Web Based GUI
- Supports 8 digital inputs, 4 MOSFETs, and 4 DC-Relays with jump switches for DI/DO mode.
- Support dry / wet contact for digital inputs.
- Support 2 hardware digital counters and 16 software virtual counters.
- Support event scheduling with holiday list.
- Support remote control IR output.
- Support digital timer for alarm outputs.
- Support CGI virtual input and HTTP Post for virtual output.
- Support meta data parsing for alarm outputs.
- Support email and FTP notification.
- Support HTTP & HTTPs Support PoE interface
| Model | DB052E |
| Digital Inputs | 8 |
| Digital Outputs-MOSFET | 4 |
| Digital Outputs-DC-Relay | 4 |
| Configurable DIOs | 8 (Via jump switch DI/O mode ) |
| COM | 1 |
| Ground | 1 |
| Isolation | 3k VDC or 2k Vrms |
| Sensor Type | Dry contact / wet contact (NPN or PNP) |
| Input Mode | DI / event counter / frequency |
| Dry Contact | Off : Open / On : Short to GND |
| Wet Contact (DI to COM) | Off : 0 – 3VDC / On : 10 – 30VDC |
| Counter Frequency | Up to 250Hz |
| Minimum Pulse Width | 500 μ sec |
| Digital Filtering Time Interval | Web GUI configurable |
| DO Mode | MOSFET Digital , N.O. / COM. |
| Over-Voltage Protection | 45 VDC max. |
| Rated current | 200 mA per channel |
| Relay Output DO Mode | DC-Relay , N.O. / N.C. / COM. |
| Operation Voltage | 24 VDC |
| Current Rating | 1A per channel |
| Network Interface/Ethernet | 10Base-T / 100Base-TX , RJ-45 |
| Protocols | ARP / TCP/IP / UDP / HTTP / HTTPS / SMTP / FTP / DDNS / NTP / DHCP / LILIN CGI |
| Security | User Account , HTTPS |
| IR Control-Sender | 1 ( 3.5mm Phone Jack), NEC protocol compatible |
| IR Control-Receiver | 1 ( 3.5mm Phone Jack), NEC protocol compatible |
| Mount Type | TS35 |
| Wiring | I/O cable max. 14 AWG |
| Operating temperature | -25°C – +50°C (-13°F – 122°F) |
| Storage temperature | -25°C – +60°C (-13°F – 140°F) |
| Relative Humidity | 0% – 80% |
| Dimensions | 170mm (W) x 60mm (H) x 98mm (D) |
| Weight | 600g |
| Power Supply | DC12V ±10% / PoE (IEEE 802.3af compliant) |
| Power Consumption | DC12V, 2.2W / PoE, 2.7W |
| I/O Status | Web GUI , Get trigger information |
| Visual Series Connection | Support |
| Languages | English, Traditional Chinese, Simplified Chinese, Russian, Italian, Hungarian, Korean, French, Turkish, Arabic, Spanish, Japanese |
| CE | Yes, EMI Class A |
| FCC | Yes, EMI Class A |
| Warranty | 1 Year |
Programmable; Smart I/O BOX; 8x DI; 4x DO MOSDET and 4x DO Relay; 4x DO MOSDET and 4x DO Relay; Web GUI; Smart Event; PoE/ DC 24V
