Planet GS-4210-24P2S front panel
Planet GS-4210-24P2S Managed Gigabit PoE Network Switch

Planet

Planet GS-4210-24P2S Managed Gigabit PoE Network Switch

$464.00
SKU: GS-4210-24P2S

Usually Ships in 10 - 12 days

Quantity:
Link to Manufacturer's Page

Contact

Planet GS-4210-24P2S Features

Hardware Specifications

  • Ethernet Ports: 24 x 10/100/1000Base-T RJ45 Auto-MDI/MDI-X Ports, 2 100/1000Base-X SFP interfaces, supporting 100/1000Mbps dual mode
  • PoE Ports: 24-Port with 802.3af/802.3at PoE injector function
  • Switch Throughput: 38.6Mpps @64 bytes
  • Switch Architecture: Store and Forward switch architecture
  • Power Requirement: AC 100~240V, 50/60Hz, 4A
  • Power Consumption: Max. 330 watts / 1122 BTU
  • LED Display: System:
    　　　Power (Green)
    10/100/1000T RJ45 Interfaces (Port 1 to Port 24):
    　　　1000 LNK / ACT (Green), 10/100 LNK/ACT (Orange), PoE (Orange)
    100/1000Mbps SFP Interfaces (Port 25 to Port 26):
    　　　1000 LNK / ACT (Green), 100 LNK/ACT (Orange)
  • Dimension (W x D x H): 440 x 207 x 45 mm, 1U height
  • Weight: 2.8 kg (6.17 lb)
  • Operating Temperature: 0 ~ 50 degrees C; 5 ~ 95% RH (non-condensing)

Power over Ethernet Specifications

  • PoE Standard: IEEE 802.3af/802.3at Power over Ethernet / PSE
  • PoE Power Supply Type: N/A
  • PoE Power Output: Per Port 52V DC, 300mA. Max. 15.4 watts (IEEE 802.3af); Per Port 52V DC, 600mA. Max. 30 watts (IEEE 802.3at)
  • Power Pin Assignments: N/A
  • PoE Power Budget: 300 watts
  • Regulation Compliance: FCC Part 15 Class A, CE
  • Standards Compliance: See datasheet

Planet GS-4210-24P2S Overview

PLANET GS-4210-24P2S is an ideal Gigabit PoE Switch which provides cost-effective advantage to local area network and is widely accepted in the SMB office network. It offers intelligent Layer 2 data packet switching and management functions, friendly web user interface and stable operation. The model complies withIEEE 802.3at Power over Ethernet Plus (PoE+) at an affordable price. The GS-4210-24P2S is equipped with24 10/100/1000Base-T Gigabit Ethernet ports and 2 100/1000Base-X SFP interfaces with inner power system. Its 24 Gigabit Ethernet ports integrated with 802.3at PoE+ injector function on all ports. It offers a rack-mountable, affordable, safe and reliable power solution for SMBs deploying Power over Ethernet networks, or requiring enhanced data security and network traffic management.
