GSD-808HP2
Planet GSD-808HP2 PoE Desktop Switch

Planet

Planet GSD-808HP2 PoE Desktop Switch

Sale price$205.00
Discontinued
SKU: GSD-808HP2

Usually Ships in 10 - 12 days

Contact

Planet GSD-808HP2 Features

Hardware Specifications

  • Ethernet Ports: 8-Port with 802.3af / 802.3at PoE injector function
  • PoE Ports: 8
  • Switch Architecture: Store and Forward switch architecture
  • Power Requirement: AC 100~240V, 50/60Hz, 1.25A
  • Power Consumption: 250 Watts / 853BTU
  • Auto Detect: Yes, Auto detect powered device (PD)
  • LED Display: System: Power x1 (Green), FAN Alert x1 (Orange), PoE Power Usage x4 (Orange), Per Port: PoE In-use (Orange), Speed (Green), LNK/ACT (Green)
  • Dimension (W x D x H): 330 x 155 x 43.5 mm
  • Weight: 1.66Kg
  • Operating Temperature: 0 ~ 50 Degree C, 5 ~ 95%, Relative Humidity, non-condensing

Power over Ethernet Specifications

  • PoE Standard: IEEE 802.3af / IEEE 802.3at Power over Ethernet / PSE
  • PoE Power Supply Type: End-Span
  • PoE Power Output: Per Port 52V DC, 275mA. Max. 15.4 Watts (IEEE 802.3af), Per Port 52V DC, 535mA. Max. 30 Watts (IEEE 802.3at)
  • Power Pin Assignments: 1/2(+), 3/6(-)
  • PoE Power Budget: 240 Watts
  • Standard Compliance: IEEE 802.3: Ethernet, IEEE 802.3u: Fast Ethernet, IEEE 802.3ab: Gigabit Ethernet, IEEE 802.3x: Flow Control, IEEE 802.3af: Power over Ethernet, IEEE 802.3at: High Power over Ethernet

Planet GSD-808HP2 Overview

High Power PoE for Security and Public Service Applications
To fulfill the High Power PoE demand of Gigabit network applications, the new member in PLANET PoE Switch family – the GSD-808HP2 is an ideal solution. The GSD-808HP2 is equipped with eight 10/100/1000Mbps PoE ports and internal power supply in a simple 13-inch, desktop size metal case. Each of the Gigabit ports feature High Power IEEE 802.3at Power over Ethernet (PoE) that enables up to 30 Watts power output per port and data transmission both delivered over one Cat.5E / 6 Ethernet cable, providing double PoE power than current 802.3af PoE injector devices.

Plug & Play PoE Function
The 8 Gigabit High Power PoE ports in the GSD-808HP2 support both 802.3af and 802.3at PoE standards to allow users flexibly deploy standard and high powered devices simultaneously with no need of software configuration. By offering 240 Watts PoE budget, maximum eight 15.4 Watts IEEE 802.3af devices or eight 30 Watts IEEE 802.3at devices can be easily installed regardless of the power-socket limitation. Simply plug in the Ethernet cables and power cord, the GSD-808HP2 is ready to provide Gigabit high speed network communication and high power PoE injector functions.

Automatic PoE Management
To facilitate power management, the GSD-808HP2 implements powerful PoE intelligent features:
■ Over Temperature Protection
■ PoE Power Usage Display
The automatic Over Temperature Protection helps to prevent power budget overloading while the temperature rises. The four orange LEDs on the right hand side of the GSD-808HP2 front panel indicates “PoE Power Usage” by four levels - 25%, 50%, 75% and 95% positioned from the bottom to the top. With these LED indications, you can monitor the PoE power status of the GSD-808HP2 easily and efficiently.

Easy Installation & Cable Connection
Providing data transfer and High Power PoE capability in one unit, the GSD-808HP2 shall reduce the need of extension cables and dedicated electrical outlets on the wall, ceiling or any unreachable place. It helps to lower the installation costs and simplify the installation effort. All RJ-45 copper interfaces in the GSD-808HP2 support 10/100/1000Mbps Auto-Negotiation for optimal speed detection through RJ-45 Category 6, 5 or 5e cables. It also supports standard Auto-MDI/MDI-X that can detect the type of connection to any Ethernet device without requiring special straight or crossover cables.
