Planet SGS-5220-24P2X front panel
Planet SGS-5220-24P2X Managed Gigabit Stackable PoE Switch

Planet

Planet SGS-5220-24P2X Managed Gigabit Stackable PoE Switch

$1,006.20
Discontinued
SKU: SGS-5220-24P2X

Usually Ships in 10 - 12 days

Link to Manufacturer's Page

Contact

Planet SGS-5220-24P2X Features

Hardware Specifications

  • Ethernet Ports: 24 x 10/ 100/1000BASE-T RJ-45 Auto-MDI/MDI-X ports, 4 x 10/100/1000Mbps TP and SFP shared combo interfaces, SFP (Mini-GBIC) supports 100/1000Mbps Dual mode DDM, shared with Port-21 to Port-24, 2 x 1/10GBASE-SR/LR SFP+ slots, 2 x 10GBASE-SR/LR SFP+ slots
  • PoE Ports: 24
  • Switch Architecture: Store and Forward
  • Switch Throughput: 95.2Mpps @64 bytes
  • Power Requirement: AC 100~240V, 50/60H
  • Power Consumption: 502 watts / 1712.8 BTU Max.
  • LED Display: System:
    PWR (Green), Master (Green),
    PWR1 (Green), PWR2 (Green), FAN1 (Green), FAN2 (Green)
    10/100/1000T RJ45 Interfaces (Port 1 to Port 24):
    10/100/1000Mbps LNK/ACT (Green)
    PoE In-Use (Orange)
    100/1000Mbps SFP Combo Interfaces (Port 21 to Port 24):
    1000Mbps (Green), LNK/ACT (Orange)
    1/10Gbps SFP+ Interfaces (Port 25 to Port 26):
    10Gbps LNK/ACT (Green), 1Gbps LNK/ACT (Orange)
    10G Stackable Interfaces (Port 27 to Port 28):
    Stack (Green), LNK/ACT (Orange)
  • Dimension (W x D x H): 440 x 300 x 44.5 mm, 1U height
  • Weight: 4887 g (10.77 lb)

Power over Ethernet Specifications

  • PoE Standard: IEEE 802.3af / IEEE 802.3at Power over Ethernet / PSE
  • PoE Power Supply Type: End-Span
  • PoE Power Output: Per Port 56V DC, Max. 30.8 Watts
  • Power Pin Assignments: 1/2(+), 3/6(-)
  • PoE Power Budget: 440 watts (max.) @ 25 degrees C, 380 watts (max.) @ 50 degrees C
  • Regulation Compliance: FCC Part 15 Class A, CE
  • Standards Compliance: See datasheet

Planet SGS-5220-24P2X Overview

For the growing Gigabit network and IoT (Internet of Things) demand, PLANET has launched a new-generation Stackable Gigabit Switch solution, the SGS-5220 switch series, to meet the needs of enterprises, telecoms and campuses for a large-scale network deployment. The SGS-5220-24P2X is Layer 2+ Stackable Managed Gigabit Switch, which supports both IPv4 and IPv6 protocols and hardware Layer 3 static routing capability, and provides 24 10/100/1000Mbps 802.3at PoE+ ports, 4 shared Gigabit SFP slots, 2 10G SFP+ uplink slots and another 2 dedicated 10G SFP+ stacked interfaces for stacking with the series of switches. Up to 16 units, 384 Gigabit Ethernet PoE+ ports and 32 10Gbps SFP+ slots can be managed by a stacking group and you can add ports and functionality as needed.
