Uniview IPC2328SBR5-DPZ 8MP Bullet IP Camera(WDR, Full Cable,PoE,Electrical Interfaces (UNI-IPC2328SBR5-DPZ)
Uniview IPC2328SBR5-DPZ 8MP Bullet IP Camera(WDR, Full Cable,PoE,Electrical Interfaces

Uniview

Uniview IPC2328SBR5-DPZ 8MP Bullet IP Camera(WDR, Full Cable,PoE,Electrical Interfaces

$719.00
Discontinued
SKU: IPC2328SBR5-DPZ

Contact

8MP Bullet IP Camera(WDR, Full Cable,PoE,Electrical Interfaces,2.8~12mm,50m IR,SD Slot,Bracket)

Optics

* LightHunter

* Day/night functionality

* Optical glass window with higher light transmittance

* IR anti-reflection window to increase the infrared transmittance

* Smart IR, up to 50m (164ft) IR distance

* Up to 120 dB Optical WDR (Wide Dynamic Range)

* 2D/3D DNR (Digital Noise Reduction)

Compression

* Ultra 265, H.265, H.264, MJPEG

* Triple streams

* ROI (Region of Interest)

* 9:16 corridor mode

Network

* ONVIF Conformance

Structure

* Support PoE power supply

* Wide temperature range: -35°C ~ 60°C (-31°F ~ 140°F)

* Wide voltage range of ±25%

* IP67

* 3-Axis

IPC2328SBR5-DPZ
Camera
Sensor 1/2", 8.0 megapixel, progressive scan, CMOS
Lens 2.8 ~ 12mm, AF automatic focusing and motorized zoom lens
DORI Distance Lens (mm) Detect (m) Observe (m) Recognize (m) Identify (m)
2.8 63 25.2 12.6 6.3
12 270 108 54 27
Angle of View (H) 114.8° ~ 47.3°
Angle of View (V) 75.3° ~ 20.4°
Angle of View (O) 141.2° ~ 55.8°
Adjustment angle Pan: 0° ~ 360° Tilt: 0° ~ 90° Rotate: 0° ~ 360°
Shutter Auto/Manual, 1 ~ 1/100000s
Minimum Illumination Colour: 0.001Lux (F1.5, AGC ON)
0Lux with IR on
Day/Night IR-cut filter with auto switch (ICR)
S/N >52dB
IR Range Up to 50m (164ft) IR range
wavelength 850nm
IR On/Off Control Auto/Manual
Defog Digital Defog
WDR 120dB
Video
Video Compression Ultra 265, H.265, H.264, MJPEG
Frame Rate Main Stream: 8MP (3840*2160), Max 20fps; 5MP (2592*1944), Max 30fps; 5MP (2944*1656), Max 30fps;
4MP (2560*1440), Max 30fps; 2MP (1920*1080), Max 60fps;
Sub Stream: 2MP (1920*1080), Max 30fps;
Third Stream: D1 (720*576), Max 30fps
Video Bit Rate 128 Kbps~16 Mbps
9:16 Corridor Mode Supported
OSD Up to 8 OSDs
Privacy Mask Up to 8 areas
ROI Up to 8 areas
Motion Detection Up to 4 areas
White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction 2D/3D DNR
Smart IR Support
Flip Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
Dewarping Support
HLC Support
BLC Support
Audio
Audio Compression G.711
Two-way audio Supported
Suppression Supported
Sampling Rate 8KHZ
Storage
Edge Storage Micro SD, up to 256GB
Network Storage ANR, NAS(NFS)
Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS
Compatible Integration ONVIF (Profile S, Profile G, Profile T), API
Client EZStation
EZView
EZLive
Web Browser Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+
Interface
Audio I/O Audio cable
Input: impedance 35kΩ; amplitude 2V [p-p]
Output: impedance 600Ω; amplitude 2V [p-p]
Alarm I/O 1/1
Network 1 RJ45 10M/100M Base-TX Ethernet
Video Output 1 BNC, impedance 75Ω; amplitude 1V [p-p]
Certifications
Certifications CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15
General
Power DC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 10W
Dimensions (L × W × H) 253.4 × 86.4 × 78.7mm (57.6” × 3.4” × 2.8”)
Net Weight 1.0kg (2.2lb)
Material Metal
Working Environment -35°C ~ 60°C (-31°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Strorage Environment -35°C ~ 60°C (-31°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
surge protection 6KV
Ingress Protection IP67
