Vivotek AP-GIC-011A-060 Indoor 60W UPoE Injector with Surge Protection

Discontinued - Recommended Replacement: AP-GIC-011B-090

Vivotek AP-GIC-011A-060 Features

• Ethernet: Gigabit Ethernet 10/100/1000Mbps (RJ45) 1
• Standards
  IEEE 802.3 10-BASE-T (Ethernet) Supported
  IEEE 802.3u 100-BASE-TX (Fast Ethernet) Supported
  IEEE 802.3ab 1000-BASE-T (Gigabit Ethernet) Supported
  IEEE 802.3at Power over Ethernet Supported
• Transmission Media
  10Base T Cat. 3, 4, 5 UTP/STP,
  100Base TX Cat. 5, 5e UTP/STP
• 1000Base T Cat. 5e, 6, 7 UTP/STP
• PoE Function
  Number of PoE Out Ports 1
  Max. PoE Output Power/ per Port 54VDC/60W
  802.3at Standard Compatible Yes
  Over Current Protection Supported
  Circuit Shorting Protection Supported
  Total PoE Power Budget 60W
  Power Pin Assignment 1/2(-), 3/6(+), 4/5(+), 7/8(-)
  PoE PD Auto Detection Supported
• General
  LED Indicators Power, PoE
  Power Input 100~240VAC/50~60Hz
  Power Consumption 65W
  Surge Protection Data/PoE port 12KV
  Surge Protection AC Power 4KV
  Dimensions 182 (L) x 78.6 (W) x 41.9 (H) mm
  Weight 0.58 kg
  Operating Temperature -10°C ~ 50°C (14°F ~ 122°F)
  Storage Temperature -20°C ~ 70°C (-4°F ~ 158°F)
  Humidity Operating: 10~90% (Non-condensing)
  Storage: 10~90% (Non-condensing)
  Safety Certifications CE, C-Tick, FCC, VCCI, LVD
• Accessory: Included Accessories Power cord, QIG
