Vivotek AW-IHT-1000
Network Camera Store is an Authorized Vivotek Reseller
Vivotek AW-IHT-1000 Industrial 8xGE PoE + 2xGE SFP Switch

Vivotek

Vivotek AW-IHT-1000 Industrial 8xGE PoE + 2xGE SFP Switch

Sale price$315.90
SKU: AW-IHT-1000
Quantity:

Contact

Vivotek AW-IHT-1000 Features

Networking Specifications

  • Gigabit Ethernet RJ45 PoE Port 8
  • Gigabit SFP Port 2

Ethernet Performance

  • Switching Bandwidth 20 Gbps
  • MAC Address 4 K
  • Buffer Memory 128 KB
  • Forwarding Capacity 14.88 Mbps
  • Jumbo Frame 9,216 Bytes
  • Transmission Method Store and Forward
  • Auto-MDI/MDI-X, Auto-Negotiation Supported

Standards

  • IEEE 802.3 10-BASE-T (Ethernet) Supported
  • IEEE 802.3u 100-BASE-TX (Fast Ethernet) Supported
  • IEEE 802.3ab 1000-BASE-T (Gigabit Ethernet) Supported
  • IEEE 802.3z 1000-BASE-X (Gigabit Ethernet) Supported
  • IEEE 802.3x Flow Control (Full-Duplex Flow Control) Supported
  • IEEE 802.3af Power over Ethernet Supported
  • IEEE 802.3at Power over Ethernet Plus Supported

Power Specifications

  • Power Input Voltage PW1: 48 ~ 56VDC, PW2: 48 ~ 56VD, Redundant Power Backup
  • Max. PoE Output Power /Per PoE Port 54VDC, Max. 30W
  • Total PoE Power Budget 240W
  • IEEE 802.3af/at Supported
  • Power Pin Assignment 1/2(+), 3/6(-)
  • PoE PD Auto Detection Supported
  • Surge Protection/Per PoE Port 12 KV

General

  • Dimensions 172 (L) x 132 (W) x 39 (H) mm
  • Weight 0.8 kg
  • Operating Temperature -40°C ~ 75°C (-40°F ~ 167°F)
  • Storage Temperature -40°C ~ 85°C (-40°F ~ 185°F)
  • Operating Humidity 5% ~ 95% non-condensing

Certifications

  • EMS EN61000-4-2 ESD, EN61000-4-3 RS, EN61000-4-4 EFT, EN61000-4-5 Surge, EN61000-4-6 CS, EN61000-4-8 PFMF
  • EMI FCC Part 15 Class A
  • Safety CE, LVD, VCCI
  • Vibration IEC 60068-2-6
  • Shock IEC 60068-2-27
  • Freefall IEC 60068-2-32
