Discontinued Recommended Replacement:
AW-IHH-0110
Vivotek AW-IHU-0100 Features
- Ethernet Ports: 1 x Gigabit Ethernet (RJ45)
-
PoE Ports: 1
- Max. PoE Output Power/per Port: 56VDC/60W
- Resolution: Megapixel/D1/VGA
- Compression: MJPEG/MPEG-4/H.264/H.265
- Compatible Cameras: VIVOTEK Network Cameras
- Power Requirement: Redundant Dual 48V-56VDC Power Input; Removable Terminal Block (Power supply not included, please refer to datasheet for options)
-
Power Consumption: 78W
- LED Display: Power, Mode A/B, 4Pair, PoE
- Dimensions: 103.5 (L) x 32 (W) x 81.5 (H) mm
- Weight: 0.14 kg (.31 lbs)
-
Operating Temperature: -40°C ~ 75°C (-40°F ~ 167°F) with 5~95% (Non-condensing)
What's Included: QIG, Terminal Block, DIN-rail Brackets, Wall Mount Kit - Warranty: 2 Years
- Please note: It is highly recommended to use standard Cat. 5e & Cat. 6 cables which are compliant with the 3P/ETL standard.
