Vivotek CM8018-90120 Adjustable Illuminator Panel

$712.50
SKU: CM8018-90120
Quantity:
Link to Manufacturer's Page

Contact

Features

  • Please Note: The CM8018 series panels are Special Order with a 4 week lead time. They are non-returnable / non-cancellable once ordered.
  • Beam Angle (Horizontal) 90° ~ 120°
  • Distance 60 ~ 70 m (196 ~ 229 ft)
  • Beam Pattern Rectangular
  • LED Array 24 pcs LED
  • Wavelength 850nm
  • External Input IR ON/OFF control
  • External Output Day/Night switching
  • Automatic IR On/Off Controlled by Light Sensor
  • Light Sensor Sensitivity 1/5/10/30(default)/50/100% (Max. 1000 Lux)(accessed via CaMate remote/RS-485 control)
  • Adjustable IR Power 20% ~ 100 % (accessed via CaMate remote/RS-485 control)
  • Power Input 24V DC ±10%, 24V AC(50/60Hz) ±10%
  • Power Consumption Max. 90 W
  • Operating Temperature -40 °C ~ +50 °C (-40 °F ~ +122 °F)
  • Working Temperature -50 °C ~ +50 °C (-58 °F ~ +122 °F)
  • Dimensions 220 x 160 x 73 mm (8.6 × 6.3 × 2.9 inch)
  • Weight 2.1 kg (4.6 lb)
  • Cable Length 0.75 m (2.46 ft) UL AWM
  • Casing IP68, IK10
  • Safety Certifications IEC 62471, EN 50130-4, CE: EN61000-6-3, EN60598-1, EN60598-2-5, FCC ClassA, EN60529
  • Humidity 90%
  • Warranty 5 years
  • Included Accessories CMA-B03 U-Type Bracket (134 × 34 × 81.5 mm)

Vivotek CM8018 Series Overview

CaMate CM80 is a series of professional IR illuminators designed with VIVOTEK’s Continuous Variable Angle Technology (CVA Tech), providing highly efficient intensity and uniform distribution to fit 10° ~ 120° FOV via adjustable beam angles up to 350 meters. The series offers multiple options for outdoor and long-distance in many applications such as traffic LPR/ANPR, airports, parking lots and many more.

The CM80 series delivers accurate image quality with special beam pattern designs such as circular (-1040), elliptical (-2040/4080) and rectangular (-90120), providing high intensity and uniformity without hot spots or overexposure issues. The radiant power of the LED’s are effectively projected on to the surveillance area. All ranges of variable angles can maintain highly efficient functionality while also conserving energy.
