Vivotek NDR-240-48 240W Single Output Industrial DIN RAIL Power Supply, 48V

NDR-240 is one economical slim 240W DIN rail power supply series, adapt to be installed on TS-35/7.5 or TS-35/15 mounting rails. The body is designed 64mm in width, which allows space saving inside the cabinets. The entire series adopts the full range AC input from 90VAC to 264VAC and conforms to EN6100-3-2, the norm the European Union regulates for harmonic current.

NDR-240 is designed with metal housing that enhances the unit’s power dissipation. With working efficiency up to 89%, the entire series can operate at the ambient temperature between -20°C and 70°C under air convection. It is equipped with constant current mode for over-load protection, fitting various inductive or capacitive applications. The complete protection functions and relevant certificates for industrial control apparatus (UL508, TUV EN60950-1, and etc.) make NDR-240 a very competitive power supply solution for industrial applications.

Key Features:

• Input 90 ~ 264 VAC
• Output 48 VDC / 240 W
• Rated Current: 5 A
• UL 508 Approved
• Cooling by free air convection
• EN61000-6-2 industrial immunity level
• Operating Temps -20~70°C
• 100% full load burn-in test
• 3-years warranty

Model Encoding:

• NDR: Series Name
• 240: Output Wattage
• 48: Output voltage
